Elektron is a lightweight, power-aware, pluggable Mesos framework that behaves as a playground to experiment with different scheduling policies to schedule ad-hoc jobs in docker containers.

This repository has been archived on 2024-04-10. You can view files and clone it, but you cannot make any changes to it's state, such as pushing and creating new issues, pull requests or comments.

Find a file

Pradyumna Kaushik e3daff5046 Removed unused json attribute varCpuShare.		2018-10-03 21:35:20 -04:00
constants	Fixed the comments to be capitalized at the start and also terminate with a period.	2017-09-28 15:36:47 -04:00
def	Runing goimports on project as well as fixing README so that headers render correctly.	2018-09-30 18:23:38 -07:00
docs	Removed commands to plug-in scheduling policies.	2018-10-03 21:32:53 -04:00
environment	Now retrieving path to rapl throttle script by reading value of an environment variable. Also, stored the RAPL_PKG_Throttle.py script in a directory called scripts/. The location of this needs to be stored in an environment variable named RAPL_PKG_THROTTLE_LOCATION.	2017-09-28 15:01:06 -04:00
logging	Runing goimports on project as well as fixing README so that headers render correctly.	2018-09-30 18:23:38 -07:00
pcp	Runing goimports on project as well as fixing README so that headers render correctly.	2018-09-30 18:23:38 -07:00
power-capping	Runing goimports on project as well as fixing README so that headers render correctly.	2018-09-30 18:23:38 -07:00
rapl	Runing goimports on project as well as fixing README so that headers render correctly.	2018-09-30 18:23:38 -07:00
schedulers	Runing goimports on project as well as fixing README so that headers render correctly.	2018-09-30 18:23:38 -07:00
scripts	Now retrieving path to rapl throttle script by reading value of an environment variable. Also, stored the RAPL_PKG_Throttle.py script in a directory called scripts/. The location of this needs to be stored in an environment variable named RAPL_PKG_THROTTLE_LOCATION.	2017-09-28 15:01:06 -04:00
utilities	Runing goimports on project as well as fixing README so that headers render correctly.	2018-09-30 18:23:38 -07:00
vendor	Adding dep files and dependencies.	2018-09-30 18:02:42 -07:00
.gitignore	added .gitignore.	2018-09-23 18:39:11 -04:00
config	updated pcp config file to not include stratos information	2017-09-26 01:40:17 -04:00
Gopkg.lock	Adding dep files and dependencies.	2018-09-30 18:02:42 -07:00
Gopkg.toml	Adding dep files and dependencies.	2018-09-30 18:02:42 -07:00
README.md	Fix title for pluggable power-capping strategies.	2018-10-03 21:30:14 -04:00
schedPolConfig.json	Removed unused json attribute varCpuShare.	2018-10-03 21:35:20 -04:00
scheduler.go	Runing goimports on project as well as fixing README so that headers render correctly.	2018-09-30 18:23:38 -07:00
workload_sample.json	updated example workload definition	2017-09-26 01:37:28 -04:00

README.md

Elektron: A Pluggable Mesos framework with power-aware capabilities

Elektron is a Mesos framework that behaves as a playground for developers to experiment with different scheduling policies to schedule ad-hoc jobs in docker containers. It is designed as a lightweight, configurable framework, which can be used in conjunction with built-in power-capping policies to reduce the peak power and/or energy usage of co-scheduled tasks.

However, in addition to being a scheduler, Elektron also takes advantage of tools such as Performance Co-Pilot and RAPL to help contain the power envelope within defined thresholds, reduce peak power consumption, and also reduce total energy consumption. Elektron is able to leverage the Mesos-provided resource abstraction to allow different algorithms to decide how to consume resource offers made by a Mesos Master.

Architecture

Usage

Logging

Please go through the logging library doc to understand how the logging library has been setup. There are also instructions on how one can add additional loggers.

Data

Cluster Resource Consumption
Schedule Trace
Degree of Collocation
When scheduling policy switching enabled.

Software Requirements

Requires Performance Co-Pilot tool pmdumptext to be installed on the machine on which electron is launched for logging to work and PCP collector agents installed on the Mesos Agents

Compatible with the following versions:

Mesos 1.5.0
Go 1.9.7

Build and Run

Compile the source code using the go build tool as shown below.

go build -o elektron

How to run (Use the --help option to get information about other command-line options):

./elektron -workload <workload json>

To run electron with Scheduling Policy Switching Enabled, run the following command,

./electron -workload <workload json> -ssp -spConfig <schedPolicy config file>

Workload schema:

[
   {
      "name": "minife",
      "cpu": 3.0,
      "ram": 4096,
      "watts": 63.141,
      "class_to_watts": {
        "A": 93.062,
        "B": 65.552,
        "C": 57.897,
        "D": 60.729
      },
      "image": "rdelvalle/minife:electron1",
      "cmd": "cd src && mpirun -np 3 miniFE.x -nx 100 -ny 100 -nz 100",
      "inst": 10
   },
   {
      "name": "dgemm",
      "cpu": 3.0,
      "ram": 32,
      "watts": 85.903,
      "class_to_watts": {
        "A": 114.789,
        "B": 89.133,
        "C": 82.672,
        "D": 81.944
      },
      "image": "rdelvalle/dgemm:electron1",
      "cmd": "/./mt-dgemm 1024",
      "inst": 10
   }
]
